A1. The front and rear frames are articulated with good performance and easy operation.
A2. Ergonomics Canopy with comfortable operation. Spring seat with belt.?View of 360°.
A3. Fully closed cab with air conditioning.
B1. 4 wheels driving and braking.
B2. The combination design of parking brake, working brake and emergency brake has good braking effect and high safety factor.?Braking model is SAHR(spring applied, hydraulic release).
B3. Rear camera to provide good view?for the operator.
B4. Full hydraulic steering system, easy and flexible operation. Hydraulic pilot control to reduce the labor intensity of the driver.
B5. Inductive switch?is equipped at the door of cab, when the door is open, the transmission will be locked to keep the vehicle safe.
Chat With Us
Leave Message
Main Technical Parameters
| Bucket | 20m3 | Capacity | 40000kg |
| Unloading Height | 5923mm | Min. Ground Clearance | 397mm |
| Oscilation Angle | ±10° | Max torque | 2757Nm / 1260rpm |
| Speed | 0-35.2km/h | Climing Ability | 20° |
| Traction | 404KN | OperationWeight | 36800kg |
Main Configuration
Engine：VOLVO TAD1650VE/ 405kw / 1900rpm
Torque Converter：DANA CL8000
Transmission：DANA 8000
Axle：DANA53R300, Rigid Planetary Axle
Hydraulic Pump：Gear Type
Wheel & Tire：TECHKING?29.5R25 ETNT
